Microprocessor Flame Photometer

Microprocessor Flame Photometer
Microprocessor Flame Photometer
Product Code : LIM-204
Brand Name : LABARD
Product Description

SALIENT FEATURES :



·         Calibration curve fit routines first order and second order

·         Data displayed in concentration units i.e. ppm & meq

·         Automatic filter selection

·         Auto calibration feature

·         Printer attachment

·         PC connecting compatibility

·         Sample data storage more than 500 results

·         Alphanumerical key board for easy data entry

·         Graphical LCD display thus easy to read

·         Curve calibration using up to 5 standard

·         Multiple calibration curve saving facility

·         Stainless steel burner

·         Auto Gas Cut off in case of power failure

·         Ca & Li Filters Extra on Request Only



PRODUCT DETAILS :



Microprocessor Flame Photometers – LIM-204 are used for the determination of sodium, potassium, calcium and lithium. They use the latest microcontroller technology and advanced engineering techniques so as to give enhanced and reproducibility. They have soft touch membrane key for ease of operations.

The sample solution is aspirated through an atomizer. Sample, Air and the fuel are mixed in the mixing chamber which is then sprayed as a very fine mist into the flame. The color of the flame is changed depending upon the concentration of elements present. Radiations from the flame passes through the sensing system and specific narrow band interference filter which permits only the characteristic radiation to pass to the photo-detector. The output of the photo-detector is then processed by the microcontroller and the final results are displayed on the 20 x 4 line alphanumeric LCD with backlit.

In both models 5-Point calibration facility and non-linearity correction is provided through an automatic curve fitting software. Facility has been provided for re-standardization with a single standard, thereby, eliminating the need of the multiple standards once a calibration has been performed.



SPECIFICATIONS :







General

Serum

Urine



Range

Na : 0.1-100 ppm Up to  250 meq/l, 1:100 dil



K : 0.1-100 ppm Up to 250 meq/l, 1:100 dil



Ca : 15-100 ppm Up to 250 meq/l, 1:100 dil



Li : 0.5-100 ppm Up to 250 meq/l, 1:100 dil



Na : 0-200 1:100 dil





K : 0-10 1:100 dil





Ca : -  Li :  0-2 1:5 dil

Na : 0-250 1:100 dil





K : 0-100  1:100 dil





Ca : -  Li  :  0-10 1:2 dil



Sensitivity

General Mode : Na : 0.5ppm , K : 0.5ppm , Li : 0.5 ppm, Ca :15ppm



Filters

Na & K Supplied (Ca & Li optional at extra cost)



Resolution

0.1 ppm / meq



Reproducibility

± 2% FS & ± 2 Digits



Curve Fit Accuracy

 ± 2 % FS



Display

20 x 4 Alphanumeric backlit LCD display



Average Time

In-built in Software



Flame System

LPG & dry oil free air



Detector

Silicon Photodiode



Calibration

Up to 5-Point Calibration with curve fitting software



Gas Control

Adjustable with knobs



Ignition System

Auto Ignition



Atomizer

Axial flow type



RS-232 Interface

Available (PC Software at extra cost)



Power

230 V, ±10 % AC, 50 Hz
